Pilz PNOZ mm0.1p User Manual

Contents
Operating Manual PNOZ mm0.1p
1002101-EN-04
4
Section 7 Operation 23
7.1 LED indicators 23
7.2 Display indicators 24
7.2.1 Rotary knob 26
7.2.1.1 Function 26
7.2.1.2 Pull out and retract the knob 26
7.2.1.3 Rotate and press the knob 26
7.2.2 Switch between menu levels 27
7.2.3 Unit diagnostics on the LC display 27
7.2.4 Error stack on the LC display 28
Section 8 Technical details 30
8.1 Safety characteristic data 33
Section 9 Supplementary data 35
9.1 Maximum capacitive load C (μF) with load current I (A) at the semicon-
ductor outputs
35
9.2 Maximum permitted total current of the semiconductor outputs 35
Section 10 Order reference 36
10.1 Product 36
10.2 Accessories 36
