PNOZ s3
Operating Manual PNOZ s3
21395-EN-10
14
Times 750103 751103
Delay-on de-energisation
With E-STOP typ. 10 ms 10 ms
With E-STOP max. 20 ms 20 ms
With power failure typ. 40 ms 40 ms
With power failure max. 60 ms 60 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 100 ms 100 ms
After power failure 100 ms 100 ms
Waiting period with a monitored re-
set
With rising edge 120 ms 120 ms
With falling edge 250 ms 250 ms
Min. start pulse duration with a
monitored reset
With rising edge 30 ms 30 ms
With falling edge 100 ms 100 ms
Supply interruption before de-ener-
gisation
20 ms 20 ms
Simultaneity, channel 1 and 2 ∞ ∞
Environmental data 750103 751103
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
EMC EN 60947-5-1, EN 61000-6-2, EN
61000-6-4
EN 60947-5-1, EN 61000-6-2, EN
61000-6-4
Vibration
In accordance with the standard EN 60068-2-6 EN 60068-2-6
Frequency 10,0 - 55,0 Hz 10,0 - 55,0 Hz
Max. amplitude 0,35 mm 0,35 mm
Airgap creepage
In accordance with the standard EN 60947-1 EN 60947-1
Overvoltage category III / II III / II
Pollution degree 2 2
Rated insulation voltage 250 V 250 V
Rated impulse withstand voltage 4,00 kV 4,00 kV
Protection type
Mounting (e.g. cabinet) IP54 IP54
Housing IP40 IP40
Terminals IP20 IP20
