PNOZ s7.1
Operating Manual PNOZ s7.1
21865-EN-11
| 18
Relay outputs 750167 751167
Utilisation category of safety con-
tacts
AC1 at 240 V 240 V
Min. current 0,003 A 0,003 A
Max. current 6 A 6 A
Min. output 0,04 VA 0,04 VA
Max. power 1500 VA 1500 VA
DC1 at 24 V 24 V
Min. current 0,003 A 0,003 A
Max. current 6 A 6 A
Min. output 0,04 W 0,04 W
Max. power 150 W 150 W
Utilisation category
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Utilisation category of safety con-
tacts
AC15 at 230 V 230 V
Max. current 5 A 5 A
DC13 (6 cycles/min) at 24 V 24 V
Max. current 5 A 5 A
Utilisation category in accordance
with UL
Voltage 240 V AC G.U. (same polarity) 240 V AC G.U. (same polarity)
With current 6 A 6 A
Voltage 24 V DC G. U. 24 V DC G. U.
With current 6 A 6 A
External contact fuse protection,
safety contacts
In accordance with the standard EN 60947-5-1 EN 60947-5-1
Max. melting integral 260 A²s 260 A²s
Blow-out fuse, quick 10 A 10 A
Blow-out fuse, slow 6 A 6 A
Blow-out fuse, gG 10 A 10 A
Circuit breaker 24V AC/DC,
characteristic B/C 6 A 6 A
Contact material AgCuNi + 0,2 µm Au AgCuNi + 0,2 µm Au
Conventional thermal current
while loading several contacts
750167 751167
Ith per contact at UB DC;
AC1:240V,DC1:24V
Conv. therm. current with 1 con-
tact 6 A 6 A
Conv. therm. current with 2 con-
tacts 5,5 A 5,5 A
Conv. therm. current with 3 con-
tacts 4,5 A 4,5 A
