Pilz PNOZ s7.1 User Manual

PNOZ s7.1
Operating Manual PNOZ s7.1
21865-EN-11
| 17
Technical details
General 750167 751167
Certifications
CCC, CE, EAC (Eurasian),
KOSHA, TÜV, cULus Listed
CCC, CE, EAC (Eurasian),
KOSHA, TÜV, cULus Listed
Electrical data 750167 751167
Supply voltage
Voltage 24 V 24 V
Kind DC DC
Voltage tolerance -20 %/+20 % -20 %/+20 %
Output of external power supply
(DC) 2 W 2 W
Residual ripple DC 20 % 20 %
Duty cycle 100 % 100 %
Max. power of all expansion mod-
ules 20 W 20 W
Inputs 750167 751167
Number 1 1
Voltage at
Input circuit DC 24 V 24 V
Current at
Input circuit DC 70 mA 70 mA
Max. inrush current impulse
Current pulse, input circuit 2 A 2 A
Pulse duration, input circuit 0,1 ms 0,1 ms
Max. overall cable resistance Rl-
max
Single-channel at UB DC 30 Ohm 30 Ohm
Relay outputs 750167 751167
Number of output contacts
Safety contacts (N/O), instant-
aneous 3 3
Max. short circuit current IK 1 kA 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1 EN 60947-4-1

Pilz PNOZ s7.1 Specifications

General

Brand	Pilz
Model	PNOZ s7.1
Category	Relays
Language	English
