Pilz PNOZ X10.1 User Manual

PNOZ X10.1
Operating Manual PNOZ X10.1
20005-EN-10
| 15
Technical details
General 774746 774749
Certifications
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
Electrical data 774746 774749
Supply voltage
Voltage 230 - 240 V 24 V
Kind AC DC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(AC) 10 VA –
Output of external power supply
(DC) – 5,5 W
Frequency range AC 50 - 60 Hz –
Residual ripple DC – 160 %
Duty cycle 100 % 100 %
Inputs 774746 774749
Number 2 2
Voltage at
Input circuit DC 24 V 24 V
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
Current at
Input circuit DC 50 mA 50 mA
Start circuit DC 100 mA 100 mA
Feedback loop DC 100 mA 100 mA
Min. input resistance at power-on 89 Ohm 89 Ohm
Max. overall cable resistance Rl-
max
Single-channel at UB DC – 45 Ohm
Single-channel at UB AC 45 Ohm –
Dual-channel without detection
of shorts across contacts at UB
DC – 90 Ohm
Dual-channel without detection
of shorts across contacts at UB
AC 90 Ohm –
Dual-channel with detection of
shorts across contacts at UB DC – 15 Ohm
Dual-channel with detection of
shorts across contacts at UB AC 15 Ohm –
Relay outputs 774746 774749
Number of output contacts
Safety contacts (N/O), instant-
aneous 6 6
Auxiliary contacts (N/C) 4 4
Max. short circuit current IK 1 kA 1 kA
