Conventional thermal current
while loading several contacts
774746 774749
Ith per contact at UB DC;
AC1:240V,DC1:24V
Conv. therm. current with 1 con-
tact – 8 A
Conv. therm. current with 2 con-
tacts – 8 A
Conv. therm. current with 3 con-
tacts – 7 A
Conv. therm. current with 4 con-
tacts – 6,1 A
Conv. therm. current with 5 con-
tacts – 5,4 A
Conv. therm. current with 6 con-
tacts – 5 A
Times 774746 774749
Switch-on delay
With automatic start typ. 180 ms 190 ms
With automatic start max. 250 ms 250 ms
With automatic start after power
on typ. 230 ms 200 ms
With automatic start after power
on max. 320 ms 300 ms
With manual start typ. 200 ms 200 ms
With manual start max. 250 ms 250 ms
With monitored start typ. 150 ms 165 ms
With monitored start max. 200 ms 220 ms
Delay-on de-energisation
With E-STOP typ. 20 ms 20 ms
With E-STOP max. 30 ms 30 ms
With power failure typ. 300 ms 300 ms
With power failure max. 400 ms 400 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 50 ms 50 ms
After power failure 450 ms 450 ms
Min. start pulse duration with a
monitored start 50 ms 50 ms
Supply interruption before de-ener-
gisation 150 ms 150 ms
Environmental data 774746 774749
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
