PNOZ X3.1
Operating Manual PNOZ X3.1
20133-EN-06
18
Times 774321 774322
Switch-on delay
With automatic start typ. 250 ms 250 ms
With automatic start max. 500 ms 500 ms
With automatic start after power
on typ. 280 ms 280 ms
With automatic start after power
on max. 550 ms 550 ms
With monitored start typ. 35 ms 35 ms
With monitored start max. 50 ms 50 ms
Delay-on de-energisation
With E-STOP typ. 15 ms 15 ms
With E-STOP max. 30 ms 30 ms
With power failure typ. 50 ms 50 ms
With power failure max. 70 ms 70 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 50 ms 50 ms
After power failure 100 ms 100 ms
Waiting period with a monitored
start
300 ms 300 ms
Min. start pulse duration with a
monitored start
30 ms 30 ms
Supply interruption before de-ener-
gisation
20 ms 20 ms
Simultaneity, channel 1 and 2 max. ∞ ∞
Environmental data 774321 774322
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -20 - 55 °C -20 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during operation Not permitted Not permitted
EMC EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
Vibration
In accordance with the standard EN 60068-2-6 EN 60068-2-6
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 0,35 mm 0,35 mm
Airgap creepage
In accordance with the standard EN 60947-1 EN 60947-1
Overvoltage category III / II III / II
Pollution degree 2 2
Rated insulation voltage 250 V 250 V
Rated impulse withstand voltage 4 kV 4 kV
