PNOZ X7
Operating Manual PNOZ X7
19692-EN-06
18
Order no. 774055 – 774057
See below for more order numbers
General 774055 774056 774057
Approvals
CCC, CE, EAC (Euras-
ian), KOSHA, TÜV, cU-
Lus Listed
CCC, CE, EAC (Euras-
ian), KOSHA, TÜV, cU-
Lus Listed
CCC, CE, EAC (Euras-
ian), KOSHA, TÜV, cU-
Lus Listed
Electrical data 774055 774056 774057
Supply voltage
Voltage 120 V 230 V 240 V
Kind AC AC AC
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 %
Output of external
power supply (AC) 2 VA 2 VA 2 VA
Frequency range AC 50 - 60 Hz 50 - 60 Hz 50 - 60 Hz
Duty cycle 100 % 100 % 100 %
Inputs 774055 774056 774057
Number 1 1 1
Voltage at
Input circuit DC 120 V 230 V 240 V
Start circuit DC 24 V 24 V 24 V
Feedback loop DC 24 V 24 V 24 V
Current at
Input circuit DC 18 mA 8 mA 7 mA
Start circuit DC 40 mA 40 mA 40 mA
Feedback loop DC 40 mA 40 mA 40 mA
Max. overall line capacit-
ance Clmax
37 nF 7 nF 7 nF
Relay outputs 774055 774056 774057
Number of output con-
tacts
Safety contacts (N/O),
instantaneous 2 2 2
Max. short circuit current
IK
1 kA 1 kA 1 kA
Utilisation category
In accordance with the
standard EN 60947-4-1 EN 60947-4-1 EN 60947-4-1
Utilisation category of
safety contacts
AC1 at 240 V 240 V 240 V
Min. current 0,01 A 0,01 A 0,01 A
Max. current 4 A 4 A 4 A
Max. power 1000 VA 1000 VA 1000 VA
DC1 at 24 V 24 V 24 V
Min. current 0,01 A 0,01 A 0,01 A
Max. current 4 A 4 A 4 A
Max. power 100 W 100 W 100 W
