Pilz PNOZ X7 User Manual

PNOZ X7
Operating Manual PNOZ X7
19692-EN-06
14
Technical details
Order no. 774049 – 774054
See below for more order numbers
General 774049 774053 774054
Approvals
CCC, CE, EAC (Euras-
ian), KOSHA, TÜV, cU-
Lus Listed
CCC, CE, EAC (Euras-
ian), KOSHA, TÜV, cU-
Lus Listed
CCC, CE, EAC (Euras-
ian), KOSHA, TÜV, cU-
Lus Listed
Electrical data 774049 774053 774054
Supply voltage
Voltage 48 V 110 V 115 V
Kind AC AC AC
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 %
Output of external
power supply (AC) 2 VA 2 VA 2 VA
Frequency range AC 50 - 60 Hz 50 - 60 Hz 50 - 60 Hz
Duty cycle 100 % 100 % 100 %
Inputs 774049 774053 774054
Number 1 1 1
Voltage at
Input circuit DC 48 V 110 V 115 V
Start circuit DC 24 V 24 V 24 V
Feedback loop DC 24 V 24 V 24 V
Current at
Input circuit DC 45 mA 14 mA 17 mA
Start circuit DC 40 mA 40 mA 40 mA
Feedback loop DC 40 mA 40 mA 40 mA
Max. overall line capacit-
ance Clmax
37 nF 37 nF 37 nF
Relay outputs 774049 774053 774054
Number of output con-
tacts
Safety contacts (N/O),
instantaneous 2 2 2
Max. short circuit current
IK
1 kA 1 kA 1 kA
Utilisation category
In accordance with the
standard
EN 60947-4-1 EN 60947-4-1 EN 60947-4-1

Pilz PNOZ X7 Specifications

General

Brand	Pilz
Model	PNOZ X7
Category	Relays
Language	English
