Pilz PNOZ X7 User Manual

PNOZ X7
Operating Manual PNOZ X7
19692-EN-06
15
Relay outputs 774049 774053 774054
Utilisation category of
safety contacts
AC1 at 240 V 240 V 240 V
Min. current 0,01 A 0,01 A 0,01 A
Max. current 4 A 4 A 4 A
Max. power 1000 VA 1000 VA 1000 VA
DC1 at 24 V 24 V 24 V
Min. current 0,01 A 0,01 A 0,01 A
Max. current 4 A 4 A 4 A
Max. power 100 W 100 W 100 W
Utilisation category
In accordance with the
standard EN 60947-5-1 EN 60947-5-1 EN 60947-5-1
Utilisation category of
safety contacts
AC15 at 230 V 230 V 230 V
Max. current 4 A 4 A 4 A
DC13 (6 cycles/min) at 24 V 24 V 24 V
Max. current 4 A 4 A 4 A
Utilisation category in ac-
cordance with UL
Voltage 240 V AC G. P. 240 V AC G. P. 240 V AC G. P.
With current 4 A 4 A 4 A
Voltage 24 V DC Resistive 24 V DC Resistive 24 V DC Resistive
With current 4 A 4 A 4 A
Pilot Duty C300, R300 C300, R300 C300, R300
External contact fuse pro-
tection, safety contacts
In accordance with the
standard EN 60947-5-1 EN 60947-5-1 EN 60947-5-1
Max. melting integral 240 A²s 240 A²s 240 A²s
Blow-out fuse, quick 4 A 4 A 4 A
Blow-out fuse, slow 4 A 4 A 4 A
Blow-out fuse, gG 4 A 4 A 4 A
Circuit breaker 24V
AC/DC, characteristic
B/C 4 A 4 A 4 A
Contact material AgSnO2 + 0,2 µm Au AgSnO2 + 0,2 µm Au AgSnO2 + 0,2 µm Au
Conventional thermal
current while loading
several contacts
774049 774053 774054
Ith per contact at UB AC;
AC1:240V,DC1:24V
Conv. therm. current
with 1 contact 4 A 4 A 4 A
Conv. therm. current
with 2 contacts
3 A 3 A 3 A

Pilz PNOZ X7 Specifications

General

Brand	Pilz
Model	PNOZ X7
Category	Relays
Language	English
