Pilz PNOZ X7 User Manual

PNOZ X7
Operating Manual PNOZ X7
19692-EN-06
16
Times 774049 774053 774054
Switch-on delay
With automatic start
typ. 230 ms 230 ms 230 ms
With automatic start
max. 700 ms 700 ms 700 ms
With automatic start
after power on typ. 230 ms 230 ms 230 ms
With automatic start
after power on max. 700 ms 700 ms 700 ms
With manual start typ. 140 ms 140 ms 140 ms
With manual start max. 700 ms 700 ms 700 ms
Delay-on de-energisation
With E-STOP typ. 70 ms 70 ms 70 ms
With E-STOP max. 100 ms 100 ms 100 ms
With power failure typ. 70 ms 70 ms 70 ms
With power failure max. 100 ms 100 ms 100 ms
Recovery time at max.
switching frequency 1/s
After E-STOP 120 ms 120 ms 120 ms
After power failure 120 ms 120 ms 120 ms
Supply interruption before
de-energisation
20 ms 20 ms 20 ms
Environmental data 774049 774053 774054
Climatic suitability EN 60068-2-78 EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during op-
eration
Not permitted Not permitted Not permitted
EMC EN 60947-5-1, EN
61000-6-2, EN 61326-3-1
EN 60947-5-1, EN
61000-6-2, EN 61326-3-1
EN 60947-5-1, EN
61000-6-2, EN 61326-3-1
Vibration
In accordance with the
standard EN 60068-2-6 EN 60068-2-6 EN 60068-2-6
Frequency 10 - 55 Hz 10 - 55 Hz 10 - 55 Hz
Amplitude 0,35 mm 0,35 mm 0,35 mm
Airgap creepage
In accordance with the
standard EN 60947-1 EN 60947-1 EN 60947-1
Overvoltage category III / II III / II III / II
Pollution degree 2 2 2
Rated insulation voltage 250 V 250 V 250 V
Rated impulse withstand
voltage 4 kV 4 kV 4 kV
