Operating Manual PNOZ X7
19692-EN-06
24
Times 774058 774059
Switch-on delay
With automatic start typ. 230 ms 50 ms
With automatic start max. 700 ms 150 ms
With automatic start after power
on typ. 230 ms 50 ms
With automatic start after power
on max. 700 ms 150 ms
With manual start typ. 140 ms 35 ms
With manual start max. 700 ms 150 ms
Delay-on de-energisation
With E-STOP typ. 70 ms 45 ms
With E-STOP max. 100 ms 70 ms
With power failure typ. 70 ms 45 ms
With power failure max. 100 ms 70 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 120 ms 50 ms
After power failure 120 ms 150 ms
Supply interruption before de-ener-
gisation
20 ms 20 ms
Environmental data 774058 774059
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during operation Not permitted Not permitted
EMC EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
Vibration
In accordance with the standard EN 60068-2-6 EN 60068-2-6
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 0,35 mm 0,35 mm
Airgap creepage
In accordance with the standard EN 60947-1 EN 60947-1
Overvoltage category III / II III / II
Pollution degree 2 2
Rated insulation voltage 250 V 250 V
Rated impulse withstand voltage 4 kV 4 kV
Protection type
Housing IP40 IP40
Terminals IP20 IP20
Mounting area (e.g. control cab-
inet) IP54 IP54
