PNOZ X9
Operating Manual PNOZ X9
19526-EN-09
15
Faults – Interference
} Earth fault: The supply voltage fails and the safety contacts open. Once the cause of
the respective fault has been rectified and the supply voltage is switched off for approx.
1minute, the unit is ready for operation again.
} Contact malfunctions: If the contacts have welded, reactivation will not be possible after
the input circuit has opened.
} LED "POWER" does not light: Short circuit or no supply voltage.
Dimensions in mm
121 (4.76")
75 (2.95")
87 (3.42")
90 (3.54")

Pilz PNOZ X9 Specifications

General

Brand	Pilz
Model	PNOZ X9
Category	Relays
Language	English
