Pilz PNOZ X9 User Manual

PNOZ X9
Operating Manual PNOZ X9
19526-EN-09
16
Technical details
Order no. 774601 – 774605
See below for more order numbers
General 774601 774605
Approvals
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
Electrical data 774601 774605
Supply voltage
Voltage 42 V 100 - 120 V
Kind AC AC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(AC) 11 VA 11 VA
Frequency range AC 50 - 60 Hz 50 - 60 Hz
Supply voltage
Voltage 24 V 24 V
Kind DC DC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(DC) 5,5 W 5,5 W
Residual ripple DC 160 % 160 %
Duty cycle 100 % 100 %
Inputs 774601 774605
Number 2 2
Voltage at
Input circuit DC 24 V 24 V
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
Current at
Input circuit DC 50 mA 50 mA
Start circuit DC 100 mA 100 mA
Feedback loop DC 100 mA 100 mA
Min. input resistance at power-on 89 Ohm 89 Ohm
Max. overall cable resistance Rl-
max
Single-channel at UB DC 45 Ohm 45 Ohm
Single-channel at UB AC 45 Ohm 45 Ohm
Dual-channel without detection
of shorts across contacts at UB
DC 90 Ohm 90 Ohm
Dual-channel without detection
of shorts across contacts at UB
AC 90 Ohm 90 Ohm
Dual-channel with detection of
shorts across contacts at UB DC 15 Ohm 15 Ohm
Dual-channel with detection of
shorts across contacts at UB AC 15 Ohm 15 Ohm
