PNOZ X9
Operating Manual PNOZ X9
19526-EN-09
20
Times 774601 774605
Delay-on de-energisation
With E-STOP typ. 20 ms 20 ms
With E-STOP max. 30 ms 30 ms
With power failure typ. 170 ms 170 ms
With power failure max. 250 ms 250 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 50 ms 50 ms
After power failure 300 ms 300 ms
Min. start pulse duration with a
monitored start
50 ms 50 ms
Supply interruption before de-ener-
gisation
35 ms 35 ms
Simultaneity, channel 1 and 2 max. 150 ms 150 ms
Environmental data 774601 774605
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Condensation during operation Not permitted Not permitted
EMC EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
EN 60947-5-1, EN 61000-6-2, EN
61326-3-1
Vibration
In accordance with the standard EN 60068-2-6 EN 60068-2-6
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 0,35 mm 0,35 mm
Airgap creepage
In accordance with the standard EN 60947-1 EN 60947-1
Overvoltage category III / II III / II
Pollution degree 2 2
Rated insulation voltage 400 V 400 V
Rated impulse withstand voltage 4 kV 4 kV
Protection type
Housing IP40 IP40
Terminals IP20 IP20
Mounting area (e.g. control cab-
inet)
IP54 IP54
Mechanical data 774601 774605
Mounting position Any Any
Mechanical life 10,000,000 cycles 10,000,000 cycles
