Pilz PNOZ X9 User Manual

PNOZ X9
Operating Manual PNOZ X9
19526-EN-09
22
Order no. 774606 –774609
General 774606 774609
Approvals
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
Electrical data 774606 774609
Supply voltage
Voltage 200 - 230 V 24 V
Kind AC AC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(AC) 11 VA 11 VA
Frequency range AC 50 - 60 Hz 50 - 60 Hz
Supply voltage
Voltage 24 V 24 V
Kind DC DC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(DC) 5,5 W 5,5 W
Residual ripple DC 160 % 160 %
Duty cycle 100 % 100 %
Inputs 774606 774609
Number 2 2
Voltage at
Input circuit DC 24 V 24 V
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
Current at
Input circuit DC 50 mA 50 mA
Start circuit DC 100 mA 100 mA
Feedback loop DC 100 mA 100 mA
Min. input resistance at power-on 89 Ohm 89 Ohm
Max. overall cable resistance Rl-
max
Single-channel at UB DC 45 Ohm 45 Ohm
Single-channel at UB AC 45 Ohm 45 Ohm
Dual-channel without detection
of shorts across contacts at UB
DC 90 Ohm 90 Ohm
Dual-channel without detection
of shorts across contacts at UB
AC 90 Ohm 90 Ohm
Dual-channel with detection of
shorts across contacts at UB DC 15 Ohm 15 Ohm
Dual-channel with detection of
shorts across contacts at UB AC
15 Ohm 15 Ohm
Semiconductor outputs 774606 774609
Number 2 2

Pilz PNOZ X9 Specifications

General

Brand	Pilz
Model	PNOZ X9
Category	Relays
Language	English
