PSEN cs1.1p
Operating Manual PSEN cs1.1p
21095-EN-10
15
Connection diagram, single connection with SDD
S21S11
24 V 0 V
A1
A2
12 22
I2 (FS)I1 (FS)
FS: Failsafe
A1
A2
Actuator
Safety switch
Evaluation device
Fieldbus module
