PSEN cs1.1p
Operating Manual PSEN cs1.1p
21095-EN-10
8
} Operating personnel are not suitably qualified
} Any type of modification has been made (e.g. exchanging components on the PCB
boards, soldering work etc.).
Disposal
} In safety-related applications, please comply with the mission time T
M
in the safety-re-
lated characteristic data.
} When decommissioning, please comply with local regulations regarding the disposal of
electronic devices (e.g. Electrical and Electronic Equipment Act).
For your safety
WARNING!
Loss of safety function due to manipulation of the interlocking device
Manipulation of the interlocking device may lead to serious injury and death.
– You should prevent any possibility of the interlocking device being
manipulated through the use of a spare actuator.
– Keep the substitute actuator in a safe place and protect it from unau-
thorised access.
– If spare actuators are used, these must be installed as described in
Installation [ 20].
– If the original actuators are replaced with substitute actuators, the ori-
ginal actuators must be destroyed before disposal.
} Do not remove the connector's protective cap until you are just about to connect the
unit. This will prevent potential contamination.
} Switch off the supply voltage before disconnecting the plug-in connection.
} Make sure that when connecting or separating the connector the pollution degree 1 or 2
is maintained.
} The connector should be protected from accidental loosening (e.g. using a cable tie).
Unit features
} Transponder technology for presence detection
} Pilz coding type: Coded
} Dual-channel operation
} 2 safety inputs for series connection of multiple safety switches
} 2 safety outputs
} Safety Device Diagnostics (SDD)
– Safety Device Diagnostics can be used to poll sensor information, to perform ac-
tions and to read configuration parameters
