PSEN cs1.1p
Operating Manual PSEN cs1.1p
21095-EN-10
22
Adjustment
} The stated operating distances (see Technical details [ 23]) only apply when the
safety switch and actuator are installed facing each other in parallel. Operating dis-
tances may deviate if other arrangements are used.
} Note the maximum permitted lateral and vertical offset (see Operating
distances [ 11] and Lateral and vertical offset [ 12]).
Operation
NOTICE
The safety function should be checked after initial commissioning and each
time the plant/machine is changed. The safety functions may only be
checked by qualified personnel.
Status indicators:
} "Power / Fault" LED illuminates green: The unit is ready for operation
} "Safety Gate" LED lights up yellow: Actuator is within the response range
} "Input" LED lights up yellow: There is a high signal at both inputs
Fault indicator:
} "Input" LED lights up yellow: The signal switches from high to low at one input, while a
high signal remains on the other input (partial operation).
Remedy: Open both channels of the input circuit.
} "Power/Fault" LED lights up red: Error message
Remedy: Rectify fault and interrupt power supply.
Please note the different times for
} The switch-on delay after UB is applied
} The recovery time of the sensor and evaluation device.
