Operating Manual PSEN cs1.1p
21095-EN-10
25
Environmental data
Ambient temperature
In accordance with the standard EN 60068-2-14
Temperature range -25 - 70 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2
Climatic suitability
In accordance with the standard EN 60068-2-78
Humidity 93 % r. h. at 40 °C
EMC EN 60947-5-3
Vibration
In accordance with the standard EN 60947-5-2
Frequency 10 - 55 Hz
Amplitude 1 mm
Shock stress
In accordance with the standard EN 60947-5-2
Acceleration 30g
Duration 11 ms
Airgap creepage
Overvoltage category III
Pollution degree 3
Rated insulation voltage 75 V
Rated impulse withstand voltage 0,8 kV
Protection type
Housing IP67
Mechanical data
Actuator 1 PSEN cs1.1
Operating distances
Assured operating distance Sao 15 mm
Typical operating distance So 21 mm
Assured release distance Sar 40 mm
Typical release distance Sr 32 mm
Repetition accuracy switching distances 10 %
Change of operating distance with temperature
changes +-0,01mm/°C
Typ. Hysteresis 3 mm
Min. distance between safety switches 400 mm
Sensor flush installation in accordance with EN
60947-5-2 Yes, follow installation guidelines
Connection type M12, 8-pin male connector
Material
Top PBT
Max. torque setting for fixing screws 1 Nm
