28
Cable
Product type Connection 1 Connection 2 Length Order no.
PSEN cable M12-8sf Straight, M12, 8-pin, socket Open cable 3 m 540 319
5 m 540 320
10 m 540 321
20 m 540 333
30 m 540 326
PSEN cable M12-8af Angled, M12, 8-pin, socket Open cable 3 m 540 322
5 m 540 323
10 m 540 324
30 m 540 325
PSEN cable M12-8sf
M12-8sm
straight, M12, 8-pin, socket Straight, M12, 8-pin, pin 2 m 540340
5 m 540341
10 540342
20 m 540343
30 m 540344
Series connection
Product type Connection X1 Connection X2
Connec-
tion X3 Order no.
PSEN Y junction M12
SENSOR
M12, 8‑pin, pin M12, 8-pin, socket M12, 8-
pin,
socket
540 315
PSEN Y junction M12
cable channel
M12, 8‑pin, pin M12, 8-pin, socket M12, 8-
pin,
socket
540 316
PSEN T junction M12 M12, 8-pin, socket M12, 8‑pin, pin M8,
4‑pin, pin
540 331
PSEN Y junction M8-M12/
M12 PIGTAIL
M12, 8-pin, socket M12, 8‑pin, pin M8,
8‑pin,
socket
540 337
PSEN Y junction M12-M12/
M12 PIGTAIL
M12, 8-pin, socket M12, 8‑pin, pin M12, 8-
pin,
socket
540 338
PDP67 F 4 code Decentralised passive junction 773 603
PDP67 F 4 code VA Decentralised passive junction, V2A ring nut 773 613
