Operating Manual PSEN cs3.1n
22172-EN-06
| 27
Times
Delay-on de-energisation
Actuator typ. 40 ms
Actuator max. 260 ms
Risk time in accordance with EN 60947-5-3 260 ms
Supply interruption before de-energisation 10 ms
Simultaneity, channel 1 and 2 max. ∞
Environmental data
Ambient temperature
In accordance with the standard EN 60068-2-14
Temperature range -25 - 70 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2
Temperature range -25 - 70 °C
Climatic suitability
In accordance with the standard EN 60068-2-78
Humidity 93 % r. h. at 40 °C
EMC EN 60947-5-3
Vibration
In accordance with the standard EN 60947-5-2
Frequency 10 - 55 Hz
Amplitude 1 mm
Shock stress
In accordance with the standard EN 60947-5-2
Acceleration 30g
Duration 18 ms
Airgap creepage
Overvoltage category III
Pollution degree 3
Rated insulation voltage 75 V
Rated impulse withstand voltage 0,8 kV
Protection type
Housing IP6K9K
Connector IP67
Operating distances
Actuator 1
Type PSEN cs3.1
Assured operating distance Sao 8 mm
Typical operating distance So 11 mm
Assured release distance Sar 20 mm
Typical release distance Sr 14 mm
Repetition accuracy switching distances 10 %
Change of operating distance with temperature
changes +-0,01mm/°C
Typ. Hysteresis 2 mm
