Pilz PSEN cs3.1n User Manual

PSEN cs3.1n
Operating Manual PSEN cs3.1n
22172-EN-06
| 26
Technical details safety switch
General
Certifications CE, EAC (Eurasian), FCC, IC, TÜV, cULus Listed
Sensor's mode of operation Transponder
Coding level in accordance with EN ISO 14119 Low
Design in accordance with EN ISO 14119 4
Classification in accordance with EN 60947-5-3 PDDB
Pilz coding type Coded
Transponder
Frequency band 122 kHz - 128 kHz
Max. transmitter output 15 mW
Electrical data
Supply voltage
Voltage 24 V
Kind DC
Voltage tolerance -20 %/+20 %
Output of external power supply (DC) 1 W
Max. switching frequency 3 Hz
Max. cable capacitance at the safety outputs
No-load, PNOZ with relay contacts 400 nF
PNOZmulti, PNOZelog, PSS 400 nF
Max. inrush current impulse
Current pulse, A1 0,58 A
Pulse duration, A1 1 ms
No-load current 20 mA
Semiconductor outputs
OSSD safety outputs 2
Signal outputs 1
Switching current per output 100 mA
Breaking capacity per output 2,4 W
Potential isolation from system voltage No
Short circuit-proof yes
Residual current at outputs 20 µA
Voltage drop at OSSDs 3,5 V
Lowest operating current 0 mA
Utilisation category in accordance with EN 60947-1 DC-12
Times
Test pulse duration, safety outputs 450 µs
Switch-on delay
after UB is applied 1 s
Actuator typ. 60 ms
Actuator max. 150 ms
