Operating Manual PSEN cs3.1n
22172-EN-06
| 31
Mechanical data 541087 541088
Max. torque setting for fixing
screws – 0,1 Nm
Dimensions
Height 3,8 mm 3,8 mm
Width 18 mm 18 mm
Depth 18 mm 18 mm
Weight 2 g 2 g
Where standards are undated, the 2016-10 latest editions shall apply.
Classification according to ZVEI, CB24I
The following tables describe the classes and specific values of the product interface and
the classes of interfaces compatible with it. The classification is described in the ZVEI posi-
tion paper "Classification of Binary 24 V Interfaces - Functional Safety aspects covered by
dynamic testing".
Single-pole output
Interfaces
Source
Interface Sensor
Class C2
Drain
Class C1, C2
Source parameters
Max. test pulse duration 450 µs
Max. rated current 0,1 A
Max. capacitive load 0,4 µF
