Pilz PSEN cs4.1n User Manual

PSEN cs4.1n
Operating Manual PSEN cs4.1n
22180-EN-06
| 28
Operating distances
Actuator 2
Type PSEN cs2.1
Assured operating distance Sao 10 mm
Typical operating distance So 25 mm
Assured release distance Sar 33 mm
Typical release distance Sr 29 mm
Repetition accuracy switching distances 10 %
Change of operating distance with temperature
changes +-0,1mm/°C
Typ. Hysteresis 3 mm
Actuator 3
Type PSEN cs4.1 low profile glue
Assured operating distance Sao 5 mm
Typical operating distance So 10 mm
Assured release distance Sar 20 mm
Typical release distance Sr 12 mm
Repetition accuracy switching distances 10 %
Change of operating distance with temperature
changes +-0,01mm/°C
Typ. Hysteresis 2 mm
Actuator 4
Typ PSEN cs4.1 low profile screw
Assured operating distance Sao 5 mm
Typical operating distance So 10 mm
Assured release distance Sar 20 mm
Typical release distance Sr 12 mm
Repetition accuracy switching distances 10 %
Change of operating distance with temperature
changes +-0,01mm/°C
Typical hysteresis 2 mm
Mechanical data
Min. bending radius (fixed permanently) K1 5 x Ø
Min. bending radius (moving) K1 10 x Ø
Cable diameter K1 5,55 mm
Min. distance between safety switches 100 mm
Sensor flush installation in accordance with EN
60947-5-2 Yes, follow installation guidelines
Connection type M12, 5-pin male connector
Cable Li9Y11Y 8 x 0,14 mm2
Material
Top PBT
Max. torque setting for fixing screws 0,8 Nm
Dimensions
Height 37 mm
Width 26 mm
Depth 18 mm
