Operating Manual PSEN cs4.1n
22180-EN-06
| 29
Mechanical data
Weight of safety switch 40 g
Where standards are undated, the 2016-10 latest editions shall apply.
Technical details actuator
Order no. 540180 - 541180
See below for more order numbers
General 540180 541180
Certifications
CE, TÜV, cULus Listed
CE, EAC (Eurasian), TÜV, cULus
Listed
Sensor's mode of operation Transponder Transponder
Coding level in accordance with EN
ISO 14119 High High
Pilz coding type fully coded fully coded
Transponder 540180 541180
Frequency band 122 kHz - 128 kHz 122 kHz - 128 kHz
Environmental data 540180 541180
Ambient temperature
In accordance with the standard EN 60068-2-14 EN 60068-2-14
Temperature range -25 - 70 °C -25 - 70 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2 EN 60068-2-1/-2
Temperature range -40 - 85 °C -25 - 70 °C
Climatic suitability
In accordance with the standard EN 60068-2-78 EN 60068-2-78
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
EMC EN 60947-5-3 EN 60947-5-3
Vibration
In accordance with the standard EN 60947-5-2 EN 60947-5-2
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 1 mm 1 mm
Shock stress
In accordance with the standard EN 60947-5-2 EN 60947-5-2
Acceleration 30g 30g
Duration 11 ms 18 ms
Protection type
Housing IP6K9K IP6K9K
Mechanical data 540180 541180
Material – PBT
Material
Top PBT –
Max. torque setting for fixing
screws 1 Nm 0,8 Nm
