Pilz PSEN cs4.1n User Manual

PSEN cs4.1n
Operating Manual PSEN cs4.1n
22180-EN-06
| 30
Mechanical data 540180 541180
Dimensions
Height 11 mm 37 mm
Width 40 mm 18 mm
Depth 40 mm 18 mm
Weight 20 g 11 g
Order no. 541187 - 541188
General 541187 541188
Certifications CE, EAC (Eurasian), TÜV, cULus
Listed
CE, EAC (Eurasian), TÜV, cULus
Listed
Sensor's mode of operation Transponder Transponder
Coding level in accordance with EN
ISO 14119 High High
Pilz coding type fully coded fully coded
Transponder 541187 541188
Frequency band 122 kHz - 128 kHz 122 kHz - 128 kHz
Environmental data 541187 541188
Ambient temperature
In accordance with the standard EN 60068-2-14 EN 60068-2-14
Temperature range -25 - 70 °C -25 - 70 °C
Max. at max. operating height +60 °C +60 °C
Max. at max. operating height
<2000 m +70 °C +70 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2 EN 60068-2-1/-2
Temperature range -40 - 85 °C -40 - 85 °C
Climatic suitability
In accordance with the standard EN 60068-2-30 EN 60068-2-30
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Max. operating height above sea
level 4000 m 4000 m
EMC EN 60947-5-3 EN 60947-5-3
Vibration
In accordance with the standard EN 60947-5-2 EN 60947-5-2
Frequency 10 - 55 Hz 10 - 55 Hz
Amplitude 1 mm 1 mm
Shock stress
In accordance with the standard EN 60947-5-2 EN 60947-5-2
Acceleration 30g 30g
Duration 11 ms 11 ms
Protection type
Housing IP67 IP67
Mechanical data 541187 541188
Material
Top PBT PBT
