PSEN sl-0.5p 1.1

Operating Manual PSEN sl-0.5p 1.1

21904-EN-10

Installing on a sliding gate

Align the actuator mounting bracket flush with the sliding

gate and tighten the screws.

Install the actuator at the height required.

Align the safety switch mounting bracket flush with the

frame and fasten with screws.

(Important: do not tighten the screws)

Fix safety switch upright with a screw (a), close gate.

(a)

Align mounting brackets, press firmly together and tighten

screw (b).

(b)
