PSEN sl-0.5p 1.1
Operating Manual PSEN sl-0.5p 1.1
21904-EN-10
25
Dimensions in mm
Power/Fault
Safety Gate
In
put
Lock
R25
44
12
2468
M5 (6x)
2559
6
26
24
45
105
121
M12x1
Fig.: Safety switch and locking magnet
52
22,5
16
R33
Ø60
138
123
7,5
14
5,3
10
10
21
M5 (2x)
2479
Fig.: Actuator
