Pilz PSEN sl-­0.5p 1.1 User Manual

PSEN sl-0.5p 1.1
Operating Manual PSEN sl-0.5p 1.1
21904-EN-10
29
Mechanical data
Sensor flush installation in accordance with EN
60947-5-2 Yes, follow installation guidelines
Connection type M12, 8-pin male connector
Cable LiYY 8 x 0.25 mm2
Material
Top PBT
Anchor plate Nickel-plated steel
Base plate Anticorodal, hard anodised
Actuator Anticorodal, hard anodised
Max. torque setting for fixing screws 3 Nm
Dimensions
Height 122 mm
Width 45 mm
Depth 44 mm
Actuator dimensions
Height 138 mm
Width 52 mm
Depth 23 mm
Weight of safety switch 570 g
Weight of actuator 375 g
Weight 950 g
Where standards are undated, the 2015-04 latest editions shall apply.
Technical Details Order No. 570560
General
Approvals CE, EAC (Eurasian), FCC, IC, TÜV, cULus Listed
Sensor's mode of operation Transponder
Coding level in accordance with EN ISO 14119 Low
Design in accordance with EN ISO 14119 4
Classification in accordance with EN 60947-5-3 PDDB
Pilz coding type Coded
Transponder
Frequency band 122 kHz - 128 kHz
Max. transmitter output 15 mW
Electrical data
Supply voltage
Voltage 24 V
Kind DC
Voltage tolerance -15 %/+10 %
Output of external power supply (DC) 4,8 W
Max. inrush current at UB 0,6 A
Max. switching frequency 1 Hz
