Pilz PSEN sl-­0.5p 1.1 User Manual

PSEN sl-0.5p 1.1
Operating Manual PSEN sl-0.5p 1.1
21904-EN-10
30
Electrical data
Max. cable capacitance at the safety outputs
No-load, PNOZ with relay contacts 40 nF
PNOZmulti, PNOZelog, PSS 70 nF
No-load current 40 mA
Inputs
Number 2
Voltage at inputs 24 V DC
Input current range 5 mA
Semiconductor outputs
OSSD safety outputs 2
Signal outputs 1
Switching current per output 500 mA
Breaking capacity per output 12 W
Short circuit-proof yes
Residual current at outputs 250 µA
Voltage drop at OSSDs 1,5 V
Conditional rated short circuit current 100 A
Lowest operating current 0 mA
Utilisation category in accordance with EN 60947-1 DC-12
Times
Test pulse duration, safety outputs 450 µs
Switch-on delay
after UB is applied 1,6 s
Inputs typ. 20 ms
Inputs max. 35 ms
Actuator typ. 500 ms
Delay-on de-energisation
Inputs typ. 20 ms
Inputs max. 35 ms
Actuator typ. 25 ms
Actuator max. 260 ms
Risk time in accordance with EN 60947-5-3 260 ms
Supply interruption before de-energisation 15 ms
Simultaneity, channel 1 and 2 max. ∞
Environmental data
Temperature of metal surface at ambient temperat-
ure: 25 °C 60 °C
Ambient temperature
In accordance with the standard EN 60068-2-14
Temperature range -25 - 55 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2
Temperature range -25 - 70 °C
