PSEN sl-0.5p 1.1
Operating Manual PSEN sl-0.5p 1.1
21904-EN-10
19
Note regarding the free-moving actuator PSEN sl-0.5fm
The free-moving actuators PSEN sl-0.5fm are fitted with a movable metal plate. For this
reason, a recess must be provided in the mounting surface for the screw connection.
A (2:1)
Ø10
3
A
91
WARNING!
Risk of death and serious injury by reaching into the danger zone!
The actuators enable a warped gate to be closed. A gap may occur on the
gate as a result. Make sure that the gap remains small enough to exclude
the possibility of reaching into the danger zone.
