Pilz PSEN sl-1.0p 1.1 User Manual

PSEN sl-1.0p 1.1/1.1 VA
Operating Manual PSEN sl-1.0p 1.1/1.1 VA
1003821-EN-12
17
Connection example PNOZs3
PNOZ s3
PSENslock
0 V
24 V
A1
A2
S22
S12
A1
A2
Y32
S31
S11
S21
12
22
2
7
8
6
1
3
4
5
Connection example PNOZmulti
3
4
8
5
PNOZmulti PSENslock
green
yellow
red
grey
I2
I0
I1
Y32
12
22
S31
A1
A2
S11
S21
2
7
6
1
A1
A2
0 V 24 V
O1
Output
element,
PNOZmulti
Legend:
I0 Input OSSD
I1 Input OSSD
I2 Signal input
O1 Lock/Unlock
Teaching in the actuator
Any corresponding Pilz actuator (see Technical details:
System with normal
actuator [
27], System with free-moving actuator [ 30], System with normal actu-
ator and stainless steel base plate [ 34]), is detected as soon as it is brought into the
response range.
