Pilz PSEN sl-1.0p 1.1 User Manual

PSEN sl-1.0p 1.1/1.1 VA
Operating Manual PSEN sl-1.0p 1.1/1.1 VA
1003821-EN-12
23
Align the safety switch to the actuator and tighten the screws.
Adjustment
} The stated operating distances (see Technical details: System with normal
actuator [ 27], System with free-moving [ 30]actuator, System with normal ac-
tuator and stainless steel base plate and actuator [ 34]) only apply when the safety
switch and actuator are installed facing each other in parallel. Operating distances may
deviate if other arrangements are used.
} Note the maximum permitted lateral and vertical offset (see Lateral and vertical
offset [ 11]).
Operation
NOTICE
The safety function should be checked after initial commissioning and each
time the plant/machine is changed. The safety functions may only be
checked by qualified personnel.
CAUTION!
Contaminated surfaces can reduce the holding force of the locking magnet.
Make sure that the contact surfaces are clean.
