Pilz PSEN sl-1.0p 1.1 User Manual

PSEN sl-1.0p 1.1/1.1 VA
Operating Manual PSEN sl-1.0p 1.1/1.1 VA
1003821-EN-12
9
Unit features
} Transponder technology for presence detection
} Pilz type of coding: coded
} different actuators available (see Order reference [ 38])
– Standard actuator PSEN sl-1.0
– free-moving actuator PSEN sl-1.0fm for special applications with higher tolerance
compensation
} Device type: PSEN sl-1.0p 1.1 VA: Base plate of switch and actuator, and connector
and screws of the device made of stainless steel
} Dual-channel operation
} 2 safety outputs
} 2 safety inputs for series connection of multiple safety switches
} 1 signal output
} Magnetic guard locking for process protection
} 1 input to switch the locking magnet on/off
} LEDs for
– Supply voltage/fault
– Gate closed
– State of the inputs
– State of the magnetic guard locking device
} M12, 8-pin male connector
