Pilz PSEN sl-1.0p 1.1 User Manual

PSEN sl-1.0p 1.1/1.1 VA
Operating Manual PSEN sl-1.0p 1.1/1.1 VA
1003821-EN-12
34
Technical Details Order No. 570630
General
Approvals CE, EAC (Eurasian), FCC, IC, TÜV, cULus Listed
Sensor's mode of operation Transponder
Coding level in accordance with EN ISO 14119 Low
Design in accordance with EN ISO 14119 4
Classification in accordance with EN 60947-5-3 PDDB
Pilz coding type Coded
Transponder
Frequency band 122 kHz - 128 kHz
Max. transmitter output 15 mW
Electrical data
Supply voltage
Voltage 24 V
Kind DC
Voltage tolerance -15 %/+10 %
Output of external power supply (DC) 7,2 W
Max. inrush current at UB 0,6 A
Max. switching frequency 1 Hz
Max. cable capacitance at the safety outputs
No-load, PNOZ with relay contacts 40 nF
PNOZmulti, PNOZelog, PSS 70 nF
No-load current 40 mA
Inputs
Number 2
Voltage at inputs 24 V DC
Input current range 5 mA
Semiconductor outputs
OSSD safety outputs 2
Signal outputs 1
Switching current per output 500 mA
Breaking capacity per output 12 W
Short circuit-proof yes
Residual current at outputs 250 µA
Voltage drop at OSSDs 1,5 V
Conditional rated short circuit current 100 A
Lowest operating current 0 mA
Utilisation category in accordance with EN 60947-1 DC-12
Times
Test pulse duration, safety outputs 450 µs

Pilz PSEN sl-1.0p 1.1 Specifications

General

Brand	Pilz
Model	PSEN sl-1.0p 1.1
Category	Accessories
Language	English
