Pilz PSEN sl-1.0p 1.1 User Manual

PSEN sl-1.0p 1.1/1.1 VA
Operating Manual PSEN sl-1.0p 1.1/1.1 VA
1003821-EN-12
33
Mechanical data
Material
Top PBT
Anchor plate Nickel-plated steel
Base plate Anticorodal, hard anodised
Actuator Anticorodal, hard anodised
Max. torque setting for fixing screws 3 Nm
Dimensions
Height 172 mm
Width 45 mm
Depth 44 mm
Actuator dimensions
Height 188 mm
Width 52 mm
Depth 22 mm
Weight of safety switch 1.120 g
Weight of actuator 590 g
Weight 1.710 g
Where standards are undated, the 2015-04 latest editions shall apply.
