Pilz PSEN sl-1.0p 1.1 User Manual

PSEN sl-1.0p 1.1/1.1 VA
Operating Manual PSEN sl-1.0p 1.1/1.1 VA
1003821-EN-12
35
Times
Switch-on delay
after UB is applied 1,6 s
Inputs typ. 20 ms
Inputs max. 35 ms
Actuator typ. 500 ms
Delay-on de-energisation
Inputs typ. 20 ms
Inputs max. 35 ms
Actuator typ. 25 ms
Actuator max. 260 ms
Risk time in accordance with EN 60947-5-3 260 ms
Supply interruption before de-energisation 15 ms
Simultaneity, channel 1 and 2 max. ∞
Environmental data
Temperature of metal surface at ambient temperat-
ure: 25 °C
65 °C
Ambient temperature
In accordance with the standard EN 60068-2-14
Temperature range -25 - 55 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2
Temperature range -25 - 70 °C
Climatic suitability
In accordance with the standard EN 60068-2-78
Humidity 93 % r. h. at 40 °C
EMC EN 55011: class A, EN 60947-5-3, EN 62061
Vibration
In accordance with the standard EN 60947-5-2
Frequency 10 - 55 Hz
Amplitude 1 mm
Shock stress
In accordance with the standard EN 60068-2-27
Number of shocks 3
Acceleration 30g
Duration 11 ms
In accordance with the standard EN 60068-2-29
Number of shocks 500
Acceleration 10g
Duration 16 ms
Airgap creepage
Overvoltage category III
Pollution degree 3
Rated insulation voltage 75 V
Rated impulse withstand voltage 1 kV
