Pilz PSEN sl-1.0p 1.1 User Manual

PSEN sl-1.0p 1.1/1.1 VA
Operating Manual PSEN sl-1.0p 1.1/1.1 VA
1003821-EN-12
28
Electrical data
Supply voltage
Voltage 24 V
Kind DC
Voltage tolerance -15 %/+10 %
Output of external power supply (DC) 7,2 W
Max. inrush current at UB 0,6 A
Max. switching frequency 1 Hz
Max. cable capacitance at the safety outputs
No-load, PNOZ with relay contacts 40 nF
PNOZmulti, PNOZelog, PSS 70 nF
No-load current 40 mA
Inputs
Number 2
Voltage at inputs 24 V DC
Input current range 5 mA
Semiconductor outputs
OSSD safety outputs 2
Signal outputs 1
Switching current per output 500 mA
Breaking capacity per output 12 W
Short circuit-proof yes
Residual current at outputs 250 µA
Voltage drop at OSSDs 1,5 V
Conditional rated short circuit current 100 A
Lowest operating current 0 mA
Utilisation category in accordance with EN 60947-1 DC-12
Times
Test pulse duration, safety outputs 450 µs
Switch-on delay
after UB is applied 1,6 s
Inputs typ. 20 ms
Inputs max. 35 ms
Actuator typ. 500 ms
Delay-on de-energisation
Inputs typ. 20 ms
Inputs max. 35 ms
Actuator typ. 25 ms
Actuator max. 260 ms
Risk time in accordance with EN 60947-5-3 260 ms
Supply interruption before de-energisation 15 ms
Simultaneity, channel 1 and 2 max. ∞
Environmental data
Temperature of metal surface at ambient temperat-
ure: 25 °C 65 °C
