22
Connections (Non-Traction) Continued
Ref. Part # Description Qty.
A MP426500 HARNESS, MAIN, PAD ASST. 1
B MP426700 HARNESS, CONT. PAN., PAD ASST. 1
C MP426800 HARNESS, MOTOR, BURNISH 1
D MP427000 HARNESS, SWITCH, TILT, HEAD 1
E MP427200 CABLE, BATTERY, 2 AWG, ASM. 1
F1 MP424200 MOTOR, 2000 RPM, ASM (20") 1
F2 MP434100 MOTOR, 1800 RPM, ASM (24") 1
G MP414800 BREAKER, CIRCUIT, 70 AMP 1
H MP207000 SOLENOID, 36VDC, SPNO 1
I MP234700 FUSE, GLASS, 3 AMP 1
J1 SA027500 CHARGER, 110V, 36V, ASM. 1
Ref. Part # Description Qty.
J2 SA027600 CHARGER, 220V, 36V, ASM. 1
K MP279700 CABEL, BATT./ CONNECTOR 1
L MP238200 CABLE, BATTERY, 13.5" 1
M MP279800 CABLE, BATT./ CONNECTOR 1
N1 MP223500 BATTERY, 12V, LEAD ACID 3
N2 MP413600 BATTERY, 12V, SEALED 3
O MP318400 SWITCH, MICRO, 12V, 1
P MP427800 WIRE, SWITCH, ORANGE 1
041613
080612
