26
Sub Assembly Continued
Ref. Part # Description Qty.
1A MP425200 SKIRT, 20", ASM. (20") 1
1B MP434200 SKIRT, 24", ASM. (24") 1
2 NB050600 BOLT, HEX, TAP, 1/4-20 x 2-1/2" 1
3 NB3350 WASHER, FLAT, 1/4" 2
4 MX1045 NUT, HEX, 1/4-20 1
5A MP139800 EDGING, SKIRT, (20") 6FT.
5B MP139800 EDGING, SKIRT, (24") 7FT.
6 MP6600 VELCRO, FELT, BLACK 2
Ref. Part # Description Qty.
7 MP423700 BRACKET, MNT, AXLE/TRANSAXLE 1
8 MP423800 TUBE, MOUNT, SHROUD, WLDMT. 1
9 MP237100 BUSHING, FLANGED, 1/2 ID X 3/8 L 6
10 NB039704 PIN, CLEVIS, 1/2" X 4-1/2" 1
11 NB025600 PIN, PRESTO, 3/32 X 1 5/8, SS 1
12 MP414300 BALL, STUD, LONG, 10MM 1
13A NB6863 BOLT, HEX, 1/2 X 1, NC (20") 1
13B NB067600 BOLT, HEX, 7/16-14 X 1", GD5 (24" & 30") 1
14A NB014600 NUT, LOCK, 1/2-13 (20") 1
14B NB067700 NUT, LOCK, 7/16-14 (24" & 30") 1
Ref. Part # Description Qty.
16A MP432600 SHROUD, 20", ASM (20") 1
16B MP438800 SHROUD, 24", ASM (24") 1
17 MP237100 BUSHING, FLANGED, 1/2 ID X 3/8 L 2
18 MP318400 SWITCH, MICRO, 12V 1
19 NB9625 SCREW, 4-40 X 3/4" 2
20 NB007000 NUT, LOCK, NYLON, 4-40 2
21 NB043800 GROMMET, 2" ID 1
22A MP415100 VELCRO, LOOP, 1", (20") 6FT.
22B MP415100 VELCRO, LOOP, 1", (24") 7FT.
23A MP424200 MOTOR, 2000 RPM, ASM (20") 1
23B MP434100 MOTOR, 1800 RPM, ASM (24") 1
24 NB6851 SCREW, CAP, HH, 3/8-16 X 3/4 4
25 MX1075 WASHER, LOCK, 3/8" 4
041613
