30
Final Bottom Assembly (Traction) Continued
Ref. Part # Description Qty.
1A MP424400 BRACKET, TRANSAXLE, ASM. (20") 1
1B MP440800 BRACKET, TRANSAXLE, ASM. (24" & 30") 1
2 MP424500 TRANSAXLE, 36 VDC, ASM. 1
3 PG001801 BRACKET, TRANSAXLE, PAINTED 2
4 NB6545 SCREW, CAP, HH, 5/16"-18 X 1" 4
5 NB3265 NUT, LOCK, 5/16"-18, NC 4
6 BA003300 KEY, 3/16 X 1.50 2
7 NB018500 RING, RETAINER, 3/4" 2
8 MP409800 WHEEL, 8" X 2", DRIVE, GREY 2
9 NB9302 SCREW, SET, 1/4-20 X 3/8 4
10 NB9505 WASHER, FLAT, 5/16" X 1 1/2' 2
11 MP432500 CASTER, 4", SWIVEL, w/ BRAKE 2
12 NB9267 WASHER, FLAT, 5/16" 20
13 NB6111 WASHER, LOCK, 5/16" 14
14 NB9745 SCREW, CAP, 5/16"-18 X 3/4" 14
041613
