Final Rear Assembly Continued
Ref. Part # Description Qty.
1 MP422901 PLATE, MOUNT, SHOCK 1
2 MP206000 BALL, STUD, 10MM 1
3 NB3265 NUT, LOCK, 5/16”-18, NC 1
4A MP415200 SPRING, GAS, (20") 1
4B MP434500 SPRING, GAS, (24") 1
4C MP450300 SPRING, GAS, (30") 1
5 NB9267 WASHER, FLAT, 5/16” 9
6 NB6111 WASHER, LOCK, 5/16” 11
7 NB9745 SCREW, CAP, 5/16”-18 X 3/4” 9
8 NB005700 NUT, 5/16-24, JAM 2
9 NB006600 NUT, KEPS, 10-32 2
Ref. Part # Description Qty.
10A SA027500 CHARGER, 110V IN, 36V OUT, ASM. 1
10B SA027600 CHARGER, 220V IN, 36V OUT, ASM. 1
10C SA028100 CHARGER, AUSTRALIAN, ASM. 1
11 MP423101 PLATE, MOUNT, CHARGER 1
12 NB6035 TIE, NYLON, 1/8 X 4, BLK 3
13 NB040400 SCREW, PAN HEAD, #10-32 UNF, X 3/4 4
14 NB006600 NUT, KEPS, 10-32 4
Ref. Part # Description Qty.
15 MP423001 PLATE, MOUNT, CONTACTOR 1
16 MP207000 SOLENOID, 36VDC, SPNO 1
17 NB6535 SCREW, CAP, HH, 1/4-20 X 3/4 2
18 NB9845 NUT, KEPS, 1/4-20 2
19 MP409401 CONTROLLER, TRAC., 36V 1
20 MX1011 SCREW, MACH, 8-32 X 1 1/4 (TRAC. ONLY) 2
21 NB9710 NUT, KEPS, 8-32, ZINC (TRAC. ONLY) 2
041613
32
