Ref. Part # Description Qty.
1 MP423201 LEVER, HANDLE, LEFT 1
2 MP423202 LEVER, HANDLE, RIGHT 1
3 NB6390 PIN, ROLL, 1/4 X 1 1/8 2
4 MP431401 PLATE, COVER, REAR, W/ SLOT 1
5 NB9267 WASHER, FLAT, 5/16” 35
6 NB61111 WASHER, LOCK, 5/16” 33
7 NB9745 SCREW, CAP, 5/16”-18 X 3/4” 30
8 NB9710 NUT, KEPS, 8-32, ZINC 2
9 NB041200 SCREW, PAN HEAD, #8 X 3/4” 2
10 MP077400 COVER, TENSION, SPRING 2
11 NB043600 SCREW, PH, HI-LO, #8 x 3/8” 6
12 MP432900 SPRING, HANDLE LEVER, 1/8”X1”X 4” 1
13 MX1025 SCREW, PAN HD. 10-24 X 3/4 2
14 NB9510 NUT, SPIN LOCK, 10-24 2
Ref. Part # Description Qty.
15 MP431600 PANEL, CONTROL, TRACTION, WLDMNT 1
16 MP426200 DECAL, CONTROL PANEL, TRACTION 1
17 MP414501 METER, HOUR/ BATTERY IND., 1
18 MP414600 SWITCH, ROCKER, DPST 1
19A MP411300 SWITCH, KEY, 36V 1
19B KC4834001 REPLACEMENT KEY (NOT SHOWN) 1
20 MP415000 SWITCH, PUSH, 250V(TRAC. ONLY) 1
21 PG016400 POTENTIOMETER, ASM. (TRAC. ONLY) 1
22 MP418000 KNOB, PHENOLIC, (TRAC. ONLY) 1
23 MP318400 SWITCH, MICRO, 12V, 15A, 1” LEVER 1
24 NB051000 SCREW, MACH., PAN HD., 4-40 X 1 2
25 NB007000 NUT, LOCK, NYLON, 4-40 4
26 SA028000 LED, RED, 36V REPLACEMENT KIT 1
Ref. Part # Description Qty.
27 MP424100 PANEL, CONTROL, PAD ASSIST 1
28 MP426300 DECAL, CONTROL PANEL, 300BU 1
29 NB9625 SCREW, 4-40 X 3/4” 2
30 MP038300 MOLDING, TRIM 16"
34
Final Top Assembly Continued
041613
