Ref. Part # Description Qty.
1 NB039704 PIN, CLEVIS, 1/2” X 4-1/2” 1
2 NB025600 PIN, PRESTO, 3/32 X 1 5/8, SS 1
3 MP423301 LATCH, TILT, SHROUD 1
4 NB026200 SCREW, SHOULDER, 3/8” X 1/2” 1
5 NB038600 SCREW, SHOULDER, 3/8 X 3-1/2 1
6 NB3265 NUT, LOCK, 5/16”-18, NC 2
7A MP414000 PADHOLDER, 20”, W/ PAD RETAINER 1
7B MP435000 PADHOLDER, 24", W/ PAD RETAINER 1
7C MP432400 RETAINER, PAD (NOT SHOWN)
8 NB023400 WASHER, FLAT, NARROW, 3/4” 1
9 SEE ROUTINE MAINTENANCE PARTS LIST
10 NB9505 WASHER, FLAT, 5/16” X 1 1/2” 1
11A MP425200 SKIRT, STEEL, 20”, ASM. 1
11B MP434200 SKIRT, STEEL, 24", ASM. 1
12 MP414100 BAG, DUST, CLOTH 1
13 MP414200 BAG, DUST, PAPER (3 PER PACK) 1
14 MP431300 COVER, DUST BAG 1
15 MP155600 KNOB, FLUTED, 1/4-20 2
16 MP423900 RETAINER, BATTERY, WELDMENT 1
17A MP415300 SPRING, COMP. (20") 1
17B MP434400 SPRING, COMP. (24") 1
17C MP448800 SPRING, COMP. (30") 1
18 NB9267 WASHER, FLAT, 5/16” 2
19 NB6111 WASHER, LOCK, 5/16” 3
20 NB9745 SCREW, CAP, 5/16”-18 X 3/4” 3
21 NB025200 WASHER, FLAT, 3/8”, SS 2
22 NB3350 WASHER, FLAT, 1/4” 4
23 NB6110 WASHER, LOCK, 1/4” 4
24 NB6530 SCREW, CAP, HH, 1/4-20 X 1 4
25 MP432700 COVER, BATTERY, w/ DECAL 1
Ref. Part # Description Qty.
26 MP422801 PLATE, MOUNT, PLUG, BATTERY 1
27A MP414800 BREAKER, CIRCUIT, 70 AMP (20" & 24") 1
27B MP444100 BREAKER, CIRCUIT, 50 AMP (30") 1
28 MP414900 BREAKER, CIRCUIT, 40 AMP (TRAC. ONLY) 1
29 MP427200 CABLE, BATT, 2 AWG, ASM. 1
30 NB6535 SCREW, CAP, HH, 1/4-20 X 3/4 2
31 NB9845 NUT, KEPS, 1/4-20 4
32 NB9000 SCREW, CAP, 1/4”-20 X 1 1/2”, GD5 2
Final Front Assembly Continued
041613
36
