Pioneer Eclipse PE300BU - Page 41

30" Shroud Assembly Continued
Ref. Part # Description Qty.
1 MP454000 SHROUD, 30", ASM. 1
2 MP237100 BUSHING, FLANGED, 1/2 ID X 3/8 L 2
3 MP318400 SWITCH, MICRO, 12V 1
4 NB9625 SCREW, 4-40 X 3/4" 2
5 NB007000 NUT, LOCK, NYLON, 4-40 2
6 MP409700 MOTOR, 2000 RPM, ASM. 1
7 BA003200 KEY, 3/16 X 1 1
8 MX1075 WASHER, LOCK, 3/8" 9
9 NB6851 SCREW, CAP, HH, 3/8-16 X 3/4 4
10 NB018600 WASHER, FLAT, 3/4" 1
11 MP445600 PULLEY, 4", 6 GROOVE 1
12 NB9505 WASHER, FLAT, 5/16" X 1 1/2" 1
13 NB6111 WASHER, LOCK, 5/16" 1
14 NB9745 SCREW, CAP, 5/16"-18 X 3/4" 1
15 NB1588 SCREW, CAP, 3/8" X 2.5 2
16 MP453300 SPACER, PULLEY, MOUNT, 1.65 L 2
17 MP453500 PULLEY, 4", 6 GROVE, ASM. 2
18 NB3450 WASHER, FLAT, 3/8" 4
19 NB046200 NUT, HEX, 3/8-16, GD5 4
20 NB010100 BOLT, CARRIAGE, 3/8-16 X 2 2
21 MP262400 IDLER, FLAT, 3.2" 2
22 MP449500 TENSIONER, BELT, ASM. 1
23 NB6042 SCREW, CAP, 3/8" X 1" 1
24 MP449100 BELT, K060620, MICRO-V 1
25 MP450100 PADHOLDER, 16", W/ SPACER, ASM. 2
26 NB6110 WASHER, LOCK, 1/4" 12
27 NB6530 SCREW, CAP, HH, 1/4-20 X 1 8
28 MP454100 COVER, BELT, W/ SEAL, ASM 1
29 NB049000 SCREW, BH, 1/4-20 X 3/4, SS 4
30 NB3350 WASHER, FLAT, 1/4" 4
31 MX1045 NUT, HEX, 1/4-20 4
32 MP415100 VELCRO, LOOP, 1" 87"
33 MP285500 SEAL, TRIM, W/BULB 87"
34 NB034800 WASHER, FLAT, FENDER, 3/8" X 1 1/2", SS 2
Ref. Part # Description Qty.
35 MP448100 PADHOLDER, 16", RET., ASM. 1
36 MP432400 RETAINER, PAD, BLUE 1
37 NB064900 SCREW, #10 x 1/2" 3
38 MP448301 PLATE, PADHOLDER, ADAPTER 1
39 NB068200 SCREW, SOCKET, 1/4-20 X 3/4 6
041613
38
