Pioneer Eclipse PE300BU - Page 43

30" Skirt, Pulley, & Tensioner Continued
Ref. Part # Description Qty.
1 MP447200 SKIRT, 30", ASM. 1
2 NB050600 BOLT, HEX, TAP, 1/4-20 x 2-1/2" 1
3 NB3350 WASHER, FLAT, 1/4" 2
4 MX1045 NUT, HEX, 1/4-20 1
5 MP8300 VELCRO, HOOK, 1" 88"
6 MP449300 MOLDING, BLK, W/ADHESIVE 88"
7 MP449200 EDGE, WEAR, FELT, 1 1/4" WIDE 1
Ref. Part # Description Qty.
8 MP449000 TENSIONER, BODY, ROTARY 1
9 MP452401 PLATE, TENSIONER, EXTENSION 1
10 MP448501 PLATE, TENSIONER, EXT., MOUNT 2
11 MP448900 IDLER, FLAT, 3.24" X 1" W 1
12 NB3450 WASHER, FLAT, 3/8" 1
13 MX1075 WASHER, LOCK, 3/8" 1
14 NB051800 SCREW, CAP, 3/8 X 1 1/4 1
15 NB6111 WASHER, LOCK, 5/16" 3
16 NB001800 BOLT, HEX, 5/16"-18 X 1 1/4" 3
Ref. Part # Description Qty.
17 MP453400 PULLEY, 4", 3/4" BORE, 6 GROOVE 1
18 MP453200 BEARING, 6203, PRECISION 2
19 NB017000 RING, INTERNAL, 40MM I.D. 2
041613
40
