Pioneer Eclipse PE440ST - Page 33

060411
Ref.Part # Description Qty.
1 MP376300 INTAKE, CARB., CLOSED LOOP 1
2 KA110137049 ELEMENT FILTER, AIR, FS481V 1
3 KA110137046 PRECLEANER, AIR, FS481V 1
4 KA490657007 FILTER, OIL, FS/FX481V 1
5 KA920702112 PLUG, SPARK, NKG, BPR4ES 1
6 KA110607016 GASKET, MUFFLER, 481V 2
7 NB8130 CLAMP, 3/4” ID, RETAINER 1
8 MP044800 ADAPTER, CONVERSION, BSPT/NPT,
1/8 X 1/8 1
9A MP028700 SWITCH, OIL PRESSURE, SINGLE-
POLE (w/ SS) 1
9B MP019200 SWITCH, OIL PRESSURE, DBL POLE
(w/o SS) 1
10 NB2460 HOSE, VACUUM, 5/32 37”
11 NB2460 HOSE, VACUUM, 5/32 45”
12 NB2470 FUEL, LINE, 3/8” 40”
13 KA461DA0800 WASHER, LOCK, 8MM 4
14 KA922107027 NUT, HEX, M8 4
15 NB7282 CLAMP, HOSE, NO.38 1
16 MP043100 SEAL, INTAKE, AIR, 1 1/2T 1
17 MP072300 DRAIN, OIL 1
18 MP4787 CLUTCH, ASM., MODEL 5215-63 1
19 MP4790 TUBING, NEOPRENE, CLUTCH ARM2”
20 MP371700 SPACER, 1.500 O.D. X 1.020 I.D. X
.285 THK 1
21 MP4805 SPACER, CLUTCH, BOTTOM, HUB
BASE 1
22 NB005800 SCREW, HEX, 7/16-20 X 1 1/2 1
23A MP018000 SENSOR, OXYGEN (w/ SAFESENSE) 1
23B MP015200 PLUG, SENSOR, OXYGEN (w/o SAFE
SENSE) 1
24 MP365300 MUFFLER, CATALYST, VERTICAL,
FS/FX481V 1
25 MP387601 BRACKET, MUFFLER, VERTICAL 1
26 MP373201 BRACKET, SWITCH, MICRO, THROTTLE1
27 MP318400 SWITCH, MICRO, 12V, 15A, 1” LEVER 1
28 NB9625 SCREW, 4-40 X 3/4” 2
29 NB006900 SCREW, 4-40 X 5/8” 1
30 NB6110 WASHER, LOCK, 1/4” 1
31 NB3350 WASHER, FLAT, 1/4” 1
32 NB007000 NUT, LOCK, NYLON, 4-40 3
33 NB038900 SPACER, THREADED, 4-40, 1/4”
OD X 1/4” LONG 1
34 NB012300 WASHER, LINKAGE, .275 HOLE &
.070 HOLE 1
35 NB007100 WASHER, FLAT, #6 1
36 NB6012 SCREW, 6mm x 20mm 1
37 NB065000 BOLT, HEX, M8 x 16, GD 8.8, ZINC 2
38 NB6111 WASHER, LOCK, 5/16” 2
39 NB9267 WASHER, FLAT, 5/16” 2
40 NB049300 SCREW, FLANGE, 1/4-20 X 1/2, ZINC 1
41 NB9545 NUT, SPIN LOCK, 1/4-20 1
42 MP027300 SPRING, RETURN, BAIL 1
43 NB8125 CLAMP, 1/4” ID, RETAINER 1
28
Engine Assembly Continued
