Pioneer Eclipse PE440ST - Page 35

060411
Frame Assembly Continued
Ref.Part # Description Qty.
1 MP391300 FRAME, ST, BLKHD, ASM. 1
2 NB6110 WASHER, LOCK, 1/4” 10
3 BA001300 AXLE, BARRACUDA 1
4 SS1315 WHEEL, 10” GRAY 2
5 MP371400 BUMPER, ROK-BAK, 12” 1
6 MP336200 STRAP, BUMPER, ROK-BAK 1
7 NB9645 WASHER, FLAT, #10 4
8 NB063400 RIVET, POP, 3/16 X 1.00 X 3/8 HD 4
9 NB3450 WASHER, FLAT, 3/8” 6
10 MX1075 WASHER, LOCK, 3/8” 6
11 NB6042 SCREW, CAP, 3/8” X 1” 2
12 BA018700 BLOCK, MOUNTING, AXLE 2
13 NB9000 SCREW, CAP, 1/4”-20 X 1 1/2”, GD5 4
14 NB2463 SCREW, SET, HEX SOCKET, 5/16-18
X 3/8 2
15 NB6044 SCREW, CAP, 3/8 X 1-1/4” 4
16 NB3350 WASHER, FLAT, 1/4” 4
17 BA014801 COVER, PULLEY 1
18 NB019100 BOLT, HEX, 1/4-20 X 3/4, GD 5 4
19 NB6530 SCREW, CAP, HH, 1/4-20 X 1 2
20A MP398001 PLATE, SPLASH, SKIRT (30”) 1
20B MP398301 PLATE, SPLASH, SKIRT, EXT. (38”) 1
21A MP391600 DECK, 30”, ASM. 1
21B MP391700 DECK, 38” ASM. 1
22 NB006400 WASHER, FENDER, 1/4 x 1-1/4 2
23 MP140000 FELT, DOT 1
30
