Bulkhead Assembly Continued
Ref.Part # Description Qty.
1 MP377300 BULKHEAD, w/ INSERTS, ASM. 1
2 MP375500 HANDLE, BULKHEAD, ADJUSTABLE,
ASM. 1
3 MP039300 PLATE, LOCK, HANDLE 2
4 NB3275 NUT, LOCK, 1/4” 8
5 NB6530 SCREW, CAP, HH, 1/4-20 X 1 6
6 MP373100 WASHER, RUBBER, 1” O.D. X .281”
I.D. X .188” THICK 2
7 NB010100 BOLT, CARRIAGE, 3/8” - 16 X 2” 2
8 RV005100 KNOB, HANDLE 2
9 NB011400 WASHER, WAVE, .642” I.D., 1” O.D.,
.105H 2
10 NB009900 GROMMET, 11/16 X 1 5
11 MP373600 HINGE, 7.5”L X 1.25”W, W/ OFFSET
HOLES 1
12 MP377200 TRAY, SWING-OUT, ASM. 1
13 MP373800 PAD, BATTERY, 5”L X 3.25”W X .12”
THK 1
14 MP280400 METER, HOUR/TACH, PANEL MOUNT 1
15 NB6514 GROMMET, 1 1/2 ID X 1/8 W X 1 3/4 D 3
16 NB034100 SCREW, PAN HD, #10-24 X 1/2”, SS 8
17 NB9510 NUT, SPIN LOCK, 10-24 8
18 NB9845 NUT, KEPS, 1/4-20 2
19 IN3510 MOUNT, TYPE S, 1/4-20 2
20 NB009800 GROMMET, 3/8 X 5/8 5
21 MP368100 STRAP, 2” x 23”, OPEN ENDS 2
22 MP367600 SLIDE, STRAP, 2”, BLK 1
23 MP199000 KEYSWITCH, IGNITION 1
24 KC4834001 KEY, STARTER SWITCH 1
25 MP042800 BOARD, DISPLAY 1
26 NB012500 SPACER, SUPPORT, PC BOARD 8
27 MP161200 MODULE, SAFESENSE 1
28 MP375600 REGULATOR, BLKHD, ASM. 1
29 KA550207015 GUARD, SCREEN 1
30 NB9645 WASHER, FLAT, #10 3
31 NB021000 RIVET, 3/16 X 1/2 X 58 HD, BLACK 3
32 MX1115 WASHER, STAR LOCK, 1/4” 2
33 NB003200 BOLT, HEX, 1/4-20 X 5/8 2
34 NB019100 BOLT, HEX, 1/4-20 X 3/4, GD 5 4
35 NB6110 WASHER, LOCK, 1/4” 4
36 NB8130 CLAMP, 3/4” ID, RETAINER 2
37 NB3350 WASHER, FLAT, 1/4” 4
38 MP367100 SOLENOID, STARTER, 12VDC 1
39A MP390400 DECAL, DASH, BLKHD, W/SS 1
39B MP390500 DECAL, DASH, BLKHD 1
40 IN1015 TRIM, BATTERY TRAY 24”
41 NB015700 SCREW, CAP, HH, 1/4-20 X 5/8 2
42 MP373300 HOSE, FUEL, LP, 34”, ASM. 1
43 MP4330 FITTING, 49 X 6, REG TO FUELOCK 1
44 MP4500 COUPLER, QUICK REGO, FEMALE 1
041411
32
NOTE: Parts listed above may not apply to units that
were not equipped with SafeSense.
